Add Arista cEOS to Containerlab on macOS

Arista has recently released a cEOS ARM64-based container image. This post will guide you through the process of downloading and importing the container image for Containerlab on macOS.

Prerequisite

• Containerlab with macOS on Apple Silicon

macOS

1. Point your web browser to the Arista Software Download page.

2. Log in with your Arista credentials.

3. Click the cEOSarm-lab-4.33.1-EFT3.tar.xz file link to download.

4. Save the cEOSarm-lab-4.33.1-EFT3.tar.xz file to your Downloads folder.

5. Open your favorite terminal emulator, and change to the Downloads directory.

cd ~/Downloads
copy

6. The download from the web browser may strip off the .xz file extension. Append if needed.

mv cEOSarm-lab-4.33.1-EFT3.tar cEOSarm-lab-4.33.1-EFT3.tar.xz
copy

7. Copy the file to the images directory on the clab Linux machine.

orb push -m clab cEOSarm-lab-4.33.1-EFT3.tar.xz ~/images/
copy

Containerlab

1. Log in to the clab Linux machine.

orb -m clab
copy

2. Change to the images directory.

cd ~/images
copy

3. Import the compressed archive with Docker.

docker import cEOSarm-lab-4.33.1-EFT3.tar.xz ceos:4.33.1-EFT3
copy

4. Verify the Arista cEOS container image is now listed.

docker images ceos
copy

output:

REPOSITORY   TAG           IMAGE ID       CREATED          SIZE
ceos         4.33.1-EFT3   27eded449f3e   5 seconds ago    2.76GB
copy

Lab

1. Change to the eos directory.

cd ~/labs/eos
copy

2. Deploy the lab.

clab deploy
copy

output:

INFO[0000] Containerlab v0.64.0 started
INFO[0000] Parsing & checking topology file: eos.clab.yml
INFO[0000] Creating docker network: Name="clab", IPv4Subnet="172.20.20.0/24", IPv6Subnet="3fff:172:20:20::/64", MTU=1500
INFO[0000] Creating lab directory: /home/marc/labs/eos/clab-eos
INFO[0000] Creating container: "sw1"
INFO[0000] Running postdeploy actions for Arista cEOS 'sw1' node
INFO[0012] Adding containerlab host entries to /etc/hosts file
INFO[0012] Adding ssh config for containerlab nodes
╭──────────────┬──────────────────┬─────────┬───────────────────╮
│     Name     │    Kind/Image    │  State  │   IPv4/6 Address  │
├──────────────┼──────────────────┼─────────┼───────────────────┤
│ clab-eos-sw1 │ ceos             │ running │ 172.20.20.2       │
│              │ ceos:4.33.1-EFT3 │         │ 3fff:172:20:20::2 │
╰──────────────┴──────────────────┴─────────┴───────────────────╯
copy

3. Test SSH connectivity to the management interface of the node.

sshpass -padmin ssh clab-eos-sw1 show version
copy

output:

Arista cEOSLab
Hardware version:
Serial number:
Hardware MAC address: 001c.730c.6262
System MAC address: 001c.730c.6262

Software image version: 4.33.1F-39308076.liffeyceoslabarm (engineering build)
Architecture: aarch64
Internal build version: 4.33.1F-39308076.liffeyceoslabarm
Internal build ID: 98fc6c22-9c8e-4226-9f9f-083a36d0bcb3
Image format version: 1.0
Image optimization: None
Kernel version: 6.12.13-orbstack-00304-gede1cf3337c4

Uptime: 0 minutes
Total memory: 8188720 kB
Free memory: 5674304 kB
copy

4. Destroy the lab.

clab destroy -c
copy
